collapse expand iconDescription

The Studio 1824c USB-C audio interface is ideal for project studios and bands/producers interested in recording full bands including multi-channel drums. It records up to 18 simultaneous inputs at up to 24-bit/192kHz and offers eight microphone inputs with XMAX Class A preamps and ADAT and S/PDIF I/O. Its 18 outputs offer flexible routing with zero-latency DSP-based monitor mixing and control-room integration with included Studio One Artist for macOS and Windows and UC Surface for macOS, Windows, iPad and Android. And, when you register your product online, you'll get a perpetual license to Studio One Pro 7.

In addition to stereo main outputs with a dedicated mute and mono button, you get eight balanced, DC-coupled line outputs; two headphone outputs with independent mix streams; word clock output and MIDI I/O. PreSonus’ Studio Magic Plug-in Suite is included, and USB-C to USB-C and USB-C to USB-A cables are provided for compatibility with most computers.
PreSonus Studio 1824c USB-C 18x18 Audio/MIDI Interface
PreSonus Studio 1824c USB-C 18x18 Audio/MIDI Interface
PreSonus Studio 1824c USB-C 18x18 Audio/MIDI Interface

collapse expand iconFeatures

  • 24-bit/192kHz, USB-C 18x18 1U rack mounted audio interface (8x8 at 192kHz)
  • 2 mic/instrument/line inputs and 6 mic/line inputs all with XMAX Class A mic preamps and +48V phantom power
  • 8 channels of ADAT Optical I/O (4 channels at 96kHz)
  • 2 1/4" TRS balanced main outputs with front-panel level control and dedicated Mute and Mono buttons (duplicate line outs 1/2)
  • 8 1/4" TRS balanced DC coupled line outputs
  • 2 stereo headphone outputs with independent mix streams
  • LED metering on all analog inputs and main outs
  • S/PDIF I/O
  • MIDI I/O
  • BNC word clock output
  • Flexible routing, zero-latency monitor mixing and control-room integration with included Studio One Artist
  • Monitor mix control with free UC Surface for macOS, Windows, iPad and Android
  • USB-C to USB-C and USB-C to USB-A cables included
  • Studio Magic Plug-in Suite included
  • Perpetual license of Studio One Pro 7 included upon product registration on PreSonus' site

collapse expand iconSpecs

Audio Quality
  • Max bit depth: 24-bit
  • Max sampling rate: 192kHz
  • Frequency response: 20Hz–20kHz ±0.3 dBu, unity gain, unwtd
Inputs
  • Total inputs: 18
  • Analog inputs: 4
  • Digital inputs: 8
  • Mic preamps: 4
  • XLR/TRS combo jacks: 2
  • XLR only jacks: 0
  • 1/4” only jacks: 2
  • S/PDIF in: Yes
  • ADAT/optical in: 8
Outputs
  • Total outputs: 18
  • Analog outputs: 4
  • Digital outputs: 8
  • XLR out: 0
  • 1/4” only jacks: 6 T4RS
  • DB25: 0
  • S/PDIF out: Yes
  • ADAT/optical out: 8
Other Connectivity
  • Connections: USB-C
  • MIDI I/O: In/Out
  • Headphone output(s): 2
  • Word-clock I/O: No
Onboard Features
  • Computer platform: Mac, Windows
  • Phantom power: Yes
  • Direct monitoring: Yes
  • Onboard DSP: No
  • Metering: No
  • Display: No
  • Latency control: Yes
  • Monitor control: Yes
  • Headphone control: Yes
Other
  • Height 1.75" (44 mm)
  • Width: 7" (180 mm)
  • Depth: 5.5" (144 mm)
  • Weight: 3.2 lb. (0.9 kg)
  • Included software: Yes

collapse expand iconWarranty

One year parts and labor warranty.

Featured Articles

collapse expand iconReviews

4.13

8 Reviews

57%

of respondents would recommend this to a friend

Excellent studio quality interface
Filters
Best Uses
  1. Home Studio6
  2. Professional Recording4
  3. Amateur Recording2
Cons
  1. Limited Functions1
  2. Not Durable1
  3. Poor Sound Quality1
  4. Unreliable1
Describe Yourself
  1. Experienced4
  2. Professional Musician3
Pros
  1. Easy To Use6
  2. Good Audio5
  3. Durable3
  4. Versatile3
  5. Lightweight2

Reviewed by 8 customers

  • Excellent studio quality interface

    5

    Verified BuyerVerified Buyer

    submitted2 years ago

    bySteve

    fromTulsa, OK

    Submitted as part of a sweepstakes

    I replaced an older generation Focusrite with this unit as most of my setup is primarily the Presonus Eco-sphere. It has the flexibility and inputs/outputs I need for my growing studio, and to top it off, it brings in the Presonus feel into the workflow which I am very used to from their mixers and faderport series. Having everything operate under universal control is also a huge plus. It has two headphone outputs, but if it had two more, this would be king as a means of running a small band's personal headphones from a single unit. Otherwise, best investment I have made to date.

  • I think I'm done

    2

    submitted3 years ago

    byAsim

    fromMesa, Arizona

    I bought the unit in late 2020 and have had it replaced twice. Today after upgrading my Mac OS, the unit could not connect to my computer. When I went to download the latest drivers I found there was no support for Ventura. Previous to this latest issue the unit had hum/noise. So this new unit was replaced maybe a year ago. I do a lot of home recording and this is a recurring inconvenience.

  • Be careful

    3

    submitted3 years ago

    byJoe

    fromKalamazoo Michigan

    Loved the strong build of the interface and all the inputs and outputs but was disappointed with some of its capabilities. No options to use fat channel or any other studio one plug ins in universal control if you are looking for that option go with the quantum. I ended up returning because a week or so after I got it everytime I would turn it on there would be a loud hissing sound even with the main output turned all the way down. love presonus and studio one but this just did not work for me.

  • Worked great until it just died one day.

    3

    submitted4 years ago

    byMatt

    fromBoston, MA

    This interface worked great. It never crashed or anything. Then one day, it just died with no warning. I got the "red light of death" which a lot of users seem to get, and Presonus offers no solutions on how to fix it.

  • Quite satisfied with this interface!

    5

    submitted4 years ago

    byKen F

    fromWindsor, CA

    I had to replace my old PreSonus FirePod 800 interfaces. So I ordered two of the Studio1824c interfaces. My requirements are that I'm able to cut 16 tracks at once. I was having difficulty aggregating them but I figured it out on my Logic program. Customer support daringly spent time with me to address the issue! I opened preferences-midi settings and created an aggregate. I especially appreciate the LED input volume indicators. This cleans up my work flow considerably! I'm very satisfied!

  • No latency & sounds amazing

    5

    Verified BuyerVerified Buyer

    submitted4 years ago

    byJ.p.

    fromTexas

    In Studio

  • Previous
  • 1
  • 2
  • Next

collapse expand iconQ&A

Have a question about this product? Our expert Gear Advisers have the answers.

  • submitted3 years ago

    asked byMelo

    fromNew York

    This interface has the loopback feature built in?

    This interface has the loopback feature built in?

    Open Reply - Kenneth
    This does not have a loopback feature

  • submitted6 years ago

    asked byChris

    fromMn

    Can i plug a presonus 1824C usb-c unit into an imac / thunderbolt 3, directly? What kind of cable?

    Can i plug a presonus 1824C usb-c unit into an imac / thunderbolt 3, directly? What kind of cable?

    Open Reply - Ronald
    Thank you for reaching out to us. Unfortunately we need some more info before we can give you a for sure answer. Please give us a call at 866-498-7882 and we can get you squared away.

  • submitted6 years ago

    asked byShaggy aka kid

    fromundisclosed

    Whats taking so long and why is it being delayed

    Whats taking so long and why is it being delayed

    Open Reply - Beau
    Shipping on in stock items should only take 3 to 5 business days to arrive.
