collapse expand iconDescription

The SSL Alpha 8 is a professional-grade 8x8 audio converter that elevates your studio with impeccable sound quality and flexible connectivity. Featuring next-generation 32-bit/192kHz converters, you'll capture every nuance with stunning clarity, immense dynamic range, ultralow noise and negligible distortion—bringing true SSL-grade performance to your rig.

Ultimate Audio Interface Expander

With its versatile routing capabilities, the Alpha 8 seamlessly integrates into your setup as the perfect audio interface expander. Connect via ADAT for up to eight channels of analog-to-digital and digital-to-analog conversion or leverage S/PDIF for an additional two channels bidirectionally. You can even configure it as an 18-in/18-out USB interface, giving you simultaneous control over all analog and digital I/O from your DAW.

Optimized Signal Integrity for Every Connection

The Alpha 8 ensures optimal signal transfer by allowing you to individually set the operating level for each analog input and output to +9, +18, +20 or +24dBu. This maximizes headroom and maintains pristine signal integrity when connecting rack gear, analog mixers, 500-series modules, monitor controllers and more. On the digital side, comprehensive clocking options with Word Clock I/O, ADAT and S/PDIF guarantee jitter-free performance.

Seamless Integration With SSL 18 and Studio Outboard

While the Alpha 8 is an exceptional interface expander for any setup, it's the perfect partner for SSL's flagship SSL 18 interface. Simply connect one or two Alpha 8 units via ADAT to instantly gain eight or 16 additional channels of I/O for effortlessly integrating analog outboard, mixers and more. The flexible routing also allows creating hardware insert paths for 500-series modules, EQs, compressors and effects processors.

Unlocking New Creative Possibilities

The Alpha 8 empowers you to expand your workflow in innovative ways. Use the S/PDIF connections to incorporate external metering or amp simulators. Electronic musicians can even route control voltages from the DC-coupled outputs to modular synths and CV-enabled effects pedals. And with the included SSL Production Pack software bundle—featuring virtual instruments, plugins, samples and a DAW—you have all the tools to bring your ideas to life.

Solid State Logic Alpha 8 8x8 A/D & D/A Audio Converter & Expander
Solid State Logic Alpha 8 8x8 A/D & D/A Audio Converter & Expander
Solid State Logic Alpha 8 8x8 A/D & D/A Audio Converter & Expander

collapse expand iconFeatures

  • High-performance next-generation 32-bit/192kHz conversion with class-leading dynamic range THD+N and crosstalk audio performance
  • 8 balanced line inputs and outputs with configurable operating levels (+24/+20/+18/+9dBu) to match external equipment
  • DC-coupled outputs ideal for sending control voltages to synthesizers and modular rigs
  • 10 digital inputs and outputs including 8 channels of ADAT and 2 channels of S/PDIF
  • Supports up to 8 channels of analog to ADAT and ADAT to analog conversion
  • 2 channels of analog to S/PDIF and S/PDIF to analog conversion
  • 2 channels of S/PDIF to ADAT and ADAT to S/PDIF conversion
  • S/PDIF available on coaxial or optical connectors
  • Flexible Conversion Configuration
  • Physical outputs can be fed with a combination of analog digital and USB audio signals for enhanced flexibility
  • 18-in/18-out USB audio interface
  • Can function as an aggregate USB audio interface enabling recording and playback of all 8 analog and 10 digital I/O via USB
  • High-current front panel headphone output for confidence checks
  • Audition any individual input or output (or stereo pair) with 3 settings to optimize for headphones: Standard, High Impedance, High Sensitivity
  • Dedicated front panel input and output meters
  • Word Clock in and out with input termination switch
  • Clock internally or from incoming ADAT S/PDIF or Word Clock
  • SSL Production Pack Software included (worth over $1,400)
